12.5mm Knauf Fire Panel Tapered Edge Plasterboard 2400mm x 1200mm (x20 Sheets)

Product information

Knauf 12.5mm Fire Panel Tapered Edge Plasterboard (2.4m x 1.2m) is designed with fire protection in mind and offers up to one hour's fire resistance with just a single layer per side of a partition.

**Boards could be supplied in Siniat depending on availability at point of order. Equivalent brands are of the same specification and price.

• Guarantee – 2 years

Features and benefits

Knauf Fire Plasterboard Applications
Knauf Fire Panel is designed to meet stringent building regulations, making it an ideal choice for installations that require enhanced fire resistance. Its superior fire performance makes it suitable for use in lining and ceiling systems in both new builds and refurbishment projects. It is commonly used in:

– Partitions
– Ceiling and lining systems
– Encasement and shaft wall systems
– Domestic separating walls

The panels can also be bonded to an insulation board on a masonry wall using Knauf Plasterboard Adhesive. For added fire protection, we recommend using two layers of gypsum plasterboard in the same build-up.

12.5mm Fireboard Fire Protection & Specifications
While it's unsettling to think about the possibility of a fire, it’s wise to use construction materials that offer additional fire resistance. The 12.5mm Knauf Fire Panel features a non-combustible, aerated gypsum core reinforced with glass fibres and additives, all bonded to pink paper liners.

A major advantage of these boards is their tapered edge, making them suitable for jointing and skimming, resulting in a smooth finish.

Key specifications include:
– Suitable for direct decoration or a Thistle gypsum plaster finish
– Designed for British Gypsum partition, wall lining, and ceiling systems
– Enhanced fire protection compared to standard plasterboards
– Board dimensions: 2400mm x 1200mm
– Special paper facing to boost fire resistance
– Manufactured with approved additives for improved fire protection
– Certified to BES 6001 with a "Very Good" rating

12.5mm Fire Panel Certifications
The 12.5mm Knauf Fire Panel meets the following standards:

– Compliance: EN 520, Types A and D
– Classified as Gypsum Type X
– Certified to BS EN ISO 9001: 2000
– Meets BS 1230: Part 1 1985
– Non-combustible according to BS 476: Part 4
